TSX-2920-15

Available


Description

The TSX-2920-15 is built for applications where gas, flammable air particles, or dust creates a hazardous environment where electrical equipment can increase the risk of explosions. This computer is Class 1 Division 2 (C1D2) certified, ensuring that it cannot emit any sparks that can cause an explosion in these hazardous settings. The stainless steel enclosure is rated IP65 waterproof and dustproof and this PC carries a MIL-STD-810F/G shock and vibration rating. The TSX-2920-15 can withstand a wide temperature range and has a fanless, highly efficient heat dissipation system. This explosion proof computer features a 1024 x 768 resolution LCD touchscreen and an Intel HD graphics video controller. With an Intel Celeron CPU, this PC can run ERP software, SCADA systems, or act as a data hub for your hazardous area application.

Key Highlights

  • 15" P-Cap Touchscreen
  • Intel Celeron N2930 Processor
  • Class 1, Division 2 Certified for Use in Hazardous Areas
  • MIL-STD-810F/G and Fully IP65 Certified
  • Wide Temperature Range (-20°C to 50°C)
  • Optional 1000 Nit High Brightness LCD

GET A QUICK QUOTE

Product Features

The TSX-2920-15 is Class 1 Division 2 (C1D2) certified and IP65 waterproof and dustproof. This 15" Rugged Panel PC also carries a MIL-STD-810F/G shock and vibration rating. The TSX-2920-15 runs on an Intel Celeron CPU.

Dimesional Drawings & I/Os

See the data sheet

Inputs / Outputs

https://teguar.com/media/wysiwyg/Product_Images_Pictures/Explosion_ProofPCs/TSX-2920-15-IOs.jpg

Technical Drawings

https://teguar.com/media/wysiwyg/Product_Images_Pictures/Explosion_ProofPCs/TSX-2920-15-Tech-Drawing.jpg

TECH SPECS

See the data sheet

Key Highlights

  • 15" P-Cap Touchscreen
  • Intel Celeron N2930 Processor
  • Class 1, Division 2 Certified for Use in Hazardous Areas
  • MIL-STD-810F/G and Fully IP65 Certified
  • Wide Temperature Range (-20°C to 50°C)
  • Optional 1000 Nit High Brightness LCD

Primary Components

Processor Family Intel Celeron Bay Trail
Processor Model N2930
Processor Speed 1.83 GHz
Memory Type 1x DDR3L SO-DIMM
Memory Support 2GB, 4GB, 8GB
Storage type mSATA
Storage support 32GB-512GB

Display

Screen Size 15"
Resolution 1024 x 768 (XGA)
Screen Ratio 16:9
Brightness 550 nits, Optional 1000 nit High Brightness
Contrast Ratio 700:1
Viewing Angle 160º (H), 140º (V)

Touch Screen

Touch Screen Projected Capacitive

External I/O ports

USB 1x M12 8Pin for USB 1/2
Serial / Com 1x COM
Serial Protocol Detail 1x M12 RS-232/RS422/RS485 Connector, Default RS232
Ethernet / LAN 1x M12 8pin RJ45 Gbe LAN
Audio 1x Audio Line-Out
Power Input Port M12 type 3-PIN DC-in

Power

Input Voltage Range 9-36V DC with Isolation
Max Power consumption 56W
Standard Power Adapter 12V / 84W AC-to-DC Adapter (not C1D2, For Testing Purposes Only)

Operating Systems

Windows Windows 10 IoT, Windows 10 Pro, Windows 7 Pro

Thermal and Environmental

Operating Temperature -20°C – 50°C
(-4°F – 122°F)
Humidity Range 10% – 95% Non-condensing
Cooling Solution Passive – Fanless

Enclosure

Material Stainless Steel
Ip Rating IP65
Vibration Rating MIL-STD-810F, MIL-STD-810G
Mounting Options VESA 100 Mount

Dimensions / Weight

Weight 11.5 KG (25.4 lbs)
Dimensions 396 x 310 x 49 mm (15.6 x 12.2 x 1.9 in)

Certification

Certifications CE, FCC

Warranty

Warranty Up to 5 Years

Accessories

See the data sheet
