Tech Specs
Primary Components
| Processor Family | Intel Core I series 14th Generation Raptor Lake |
| Processor Model | Core i7-14700 |
| Memory Type | 32GB (2x 16GB) Wide Temp DDR5 SO-DIMM |
| Storage Type | 1x 1TB Wide Temp 2.5" SATA SSD |
External I/O Ports
| USB | 8x USB 3.2 Gen 2 |
| Serial / Com | 3x COM |
| Serial Protocol Detail | 3x RS232/RS422/RS485 |
| Ethernet / LAN | 4x RJ45 2.5Gbe LAN |
| Other Ports | 1x 2-Pin DC Power Switch Connector, 1x 2-PIN Power Reset Connector, 1x 8-bit GPIO (in DB9 Connector) |
| Audio Ports | 1x Audio Line-Out, 1x Mic-In |
| Power Input Port | 3-Pin DC-In (Phoenix Type) |
Power
| Input Voltage Range | 9-48V DC |
| Standard Power Adapter | 300W (24V/12..5A) External Power Supply |
Operating Systems
| Linux | Linux Ubuntu 22.04 |
Compatibility
| Security Hardware | TPM 2.0 |
Expansion Slots
| Internal M.2 | 1x M.2 2230 Key E (for WiFi expansion option), 1x M.2 2260/2242 B-Key (USB2.0 / PCIeX1 / SATAIII), 1x M.2 2280/2260/2242 M-Key (PCIe x4 NVMe, SATAIII) |
| Expansion Module support | Internal PoE+ Expansion (For RJ45 Ports Already Included, Does not take up Expansion Bay Slot) |
| Video Card Support | NVIDIA RTX 2000 ADA |
Thermal & Environmental
| Operating Temperature | -40°C - 50°C (-40°F to 122°F (with 0.7m/s Air Flow and Wide Temperature Memory/Storage)) |
| Storage Temperature | -40°C - 85°C (-40°F – 185°F) |
| Cooling Solution | CPU - Passively Cooled with Heatsink, PCIe Expansion Area - Actively Cooled with 2x 40x40x20mm Fans |
| Storage Humidity | 10%~95%, non-condensing |
Enclosure
| Material | Aluminum |
| Color | Black & Blue |
| Led Indicator Light | 1x DIO, 1x Power, 1x Storage, 4x LAN |
| Control Buttons | Power Button |
| Mounting Options | Wall Mount |
Peripherals & Wireless Connectivity
| WiFi | Optional WiFi 6E |
| Bluetooth | Optional Bluetooth 5.2 |
| Sim Card | 2x SIM Card Slot |
Weight / Dimensions
| Weight | 7.7 kg (17.0 lbs) |
| Dimensions | 268 x 246 x 128 mm (10.6 x 9.7 x 5.0 in) |
Certification
| Certifications | CE, FCC |
