TP-5040-22

22" Industrial Fanless PC
Available – Contact Us for Quick Quote

Description

This industrial computer has a 21.5″ widescreen P-cap touchscreen and runs on the powerful Intel Skylake core i3/i5 CPU. The TP-5040-22 utilizes fanless cooling and is built with rugged aluminum housing. The front bezel of this computer is IP65 rated waterproof, so it can easily be sprayed and wiped down for cleaning. This PC has options for a webcam, Bluetooth, RFID and barcode reader, for seamless integration into your system. This reliable computer is designed for 24/7 operation in even the most demanding of work environments.

This product is now considered “Previous Generation” meaning it may or may not still be available for purchase. Call +1 800 870 7715 for details on this product or check out our full list of currently available Panel PCs.



Key Highlights

  • 21.5″ True Flat IP65 Protected Touchscreen
  • Intel SkyLake Core i3/i5 CPU
  • Fanless and low power consumption
  • Thin, Attractive, Design with Die-Cast Housing
  • Several I/O Ports and an HDD Bay

Primary Components

Processor FamilyIntel Core I series 6th Generation Skylake
Processor ModelCore- i3-6100U
Processor Speed2.0 GHz
Memory Type1x DDR3 SO-DIMM
Memory Support2GB, 4GB, 8GB
Storage Type1x 2.5" SATA Drive Bay for SSD/HDD
Storage Support32GB-1TB

Display

Screen Size21.5
Resolution1920 x 1080 (Full HD)
Screen Ratio16:9
Brightness250 nits

Touch Screen

Touch ScreenProjected Capacitive

External I/O Ports

USB2x USB 2.0, 4x USB 3.0
Ethernet / LAN2x RJ45 GbE LAN
Video Outputs1x Optional DisplayPort, 1x VGA
Audio Ports1x Audio Line-In, 1x Audio Line-Out
Power Input Port4-Pole DIN (latching)

Power

Input Voltage Range12-48V DC for Core i5 CPU, 19V only for Core i3 CPU

Operating Systems

WindowsWindows 10 IoT, Windows 10 Pro

Compatibility

Security HardwarefTPM 2.0, Intel vPro Technology: Intel AMT Supported

Multimedia

Speakers2x 2W Speakers
Camera2MP Webcam

Thermal & Environmental

Operating Temperature0°C - 35°C (32°F – 95°F)
Storage Temperature-20°C - 60°C (-4°F – 140°F)
Cooling SolutionPassive – Fanless
Humidity Range20% – 85% Non-condensing

Enclosure

MaterialAluminum
IP RatingIP65 Front Bezel
Mounting OptionsVESA 75 Mount

Peripherals & Wireless Connectivity

WiFiOptional 802.11 b/g/n WLAN card + Bluetooth 4.0
Barcode ScannerOptional 1D/2D Barcode Scanner
RFIDOptional RFID Module

Weight / Dimensions

Weight7.75 kg (17.1 lbs)
Dimensions536 x 48 x 328 mm (21.1 x 1.9 x 12.9 in)

The TP-5040-22 has a large, Pcap touchscreen, measuring 21.5” in a widescreen format. This industrial strength computer runs on an Intel Skylake i3/i5 CPU and has a fanless cooling system.

Dimensional Drawings & I/Os

I/O Diagram Images

tp-5040-22 i/os

Tech Diagram Images

tp-5040-22 tech drawing
