Tech Specs
Primary Components
| Processor Family | Intel Core I series 6th Generation Skylake |
| Processor Model | Core i5-6200 |
| Processor Speed | 2.3 GHz |
| Memory Type | 2x DDR4 SO-DIMM |
| Memory Support | 4GB, 8GB, 16GB, 32GB |
| Storage Type | 1x 2.5" SATA Drive Bay for SSD/HDD |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 19 |
| Resolution | 1280 x 1024 (SXGA) |
| Screen Ratio | 5:4 |
| Brightness | 350 nits |
Touch Screen
| Touch Screen | Projected Capacitive (Multi-touch) |
| Hardness | 7H |
External I/O Ports
| USB | 4x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232, 1x RS-232/422/485 (RS485 supports auto flow control, Jumperless configuration in BIOS) |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 2x DisplayPort |
| Other Ports | 4KV Isolation Option is 2x ISO COM, 1x ISO LAN, 1x ISO USB 2.0 |
| Audio Ports | 1x 3.5mm Microphone Jack, 1x Audio Line-Out |
Power
| Max Power Consumption | 88W |
| Standard Power Adapter | AC 90V~264V / 47-63 Hz |
Battery
| Battery Type | Optional Internal Battery |
Operating Systems
| Windows | Windows 10 IoT, Windows 10 Pro, Windows 7 Pro |
Compatibility
| Security Hardware | TPM v2.0 (Windows 10 Only) |
Expansion Slots
| Internal M.2 | 1x M.2 Type E |
| Video Card Support | Intel Integrated HD Graphics 520 |
Multimedia
| Speakers | 2x 2W Speakers |
| Camera | Optional 3MP Webcam |
Thermal & Environmental
| Operating Temperature | 0°C - 35°C (32°F – 95°F) |
| Storage Temperature | -20°C - 60°C (-4°F – 140°F) |
| Cooling Solution | Passive – Fanless |
| Humidity Range | 10% – 90% Non-condensing |
| Storage Humidity | 10% – 90% Non-condensing |
Enclosure
| Material | Plastic |
| IP Rating | IP65 Front Bezel |
| Color | White |
| Led Indicator Light | Battery, HDD Access, Power |
| Control Buttons | Audio Down, Audio Up, Brightness Down, Brightness Up, Clean me, Display on/off, Power Button |
| Shock Rating | Operating: 11 ms, half sine wave |
| Drop Rating | 3ft Drop Protection |
| Mounting Options | Desktop Stand, VESA Mount, Wall Mount |
Peripherals & Wireless Connectivity
| WiFi | Optional 802.11 a/b/g/n/AC WLAN module + Optional Bluetooth |
| RFID | Optional RFID reader (13.56Hz) (5V USB) |
Weight / Dimensions
| Weight | 7.5 kg (16.5 lbs) |
| Dimensions | 450 x 420 x 85.3 mm (17.7 x 16.5 x 3.4 in) |
Certification
| Certifications | CE, FCC Class B, VCCI, 60601-1 4th Edition |
Warranty
| Warranty | Up to 5 Years |
