Tech Specs
Primary Components
| Processor Family | Intel Atom CherryTrail |
| Processor Model | Z8350 |
| Processor Speed | 1.44 GHz |
| Memory Type | Onboard DDR3 |
| Memory Support | 4GB |
| Storage Support | 32GB (Standard), up to 128GB (Optional) |
Display
| Screen Size | 8" |
| Resolution | 1280 x 800 (WXGA), 1920 x 1080 (Full HD) |
| Screen Ratio | 16:10 |
| Brightness | Optional 700 nit High Brightness, 400 nits |
Touch Screen
| Touch Screen | Projected Capacitive (Multi-touch) |
| Glass Type | Gorilla Glass |
External I/O Ports
| USB | 1x Micro USB Port, 1x USB 2.0 |
| Video Outputs | 1x Mini HDMI |
| Audio Ports | 1x 3.5mm Headphone Jack |
| Power Input Port | 3.5mm DC-in Jack |
Power
| Standard Power Adapter | AC 100V~240V, 50Hz/60Hz output 5V/3A |
Battery
| Battery Type | Internal 3.7V/8500mAh Battery |
| Battery Operating Time | 7hrs (Default 50% volume, 50% Brightness, Playing 1080P Video) |
Operating Systems
| Windows | Windows 10 IoT, Windows 10 Pro |
| Android | Android 5.X |
Compatibility
| Security Hardware | fTPM 2.0 |
Expansion Slots
| Video Card Support | Intel HD Graphics |
| SD card | 1x Micro SD Slot |
| Other | Pogo Pin Expansion |
Multimedia
| Speakers | 1x 0.8W Speaker |
| Camera | Front: 2MP, Rear: 5MP |
| Microphone | Built-in Microphone |
Thermal & Environmental
| Operating Temperature | -20°C - 60°C (-4°F – 140°F) |
| Storage Temperature | -30°C - 70°C (-22°F – 158°F) |
| Cooling Solution | Passive – Fanless |
| Humidity Range | 95% Non-condensing |
Enclosure
| Material | Double Injection |
| IP Rating | IP67 |
| Color | Black |
| Shock Rating | MIL-STD-810G |
| Mounting Options | Desktop Stand, Forklift Mount, Vehicle Mount |
| Approved Cleaning Solutions | Acetone, Actichlor, Alcohol, Ammonium Nitrate (low concentration), Antigone, Betasept, Bleach, Caviwipes, Chloride, CIDEX, Control III Disinfectant Germicide, Dispatch Disinfectant Cleaner CLH69101, Incidin, Isopropyl Alcohol, LpH se, MikroBac, Mikrozid, Peridox, Puregreen 24 Disinfectant, SDW 70C, Sodium Hypochlorite, SporeClear, Trigene, Viraguard, Virkon, Windex, 3M HB Quat |
Peripherals & Wireless Connectivity
| WiFi | Wi-Fi a/b/g/n/ac |
| Bluetooth | Bluetooth 4.1 |
| Mobile Network 4G LTE | Optional Onboard Quectel 4G LTE , North America,South America, EMEA, Austrailia/NZ |
| Barcode Scanner | Optional 1D/2D Barcode Scanner |
| RFID | Optional RFID Scanner |
| Peripheral Other | Cigarette adapter; Digitizer Pen; Handstrap; Desktop Dock; Vehicle Dock; Forklift Dock; Shoulder Strap; Back Strap; Mounts |
| Sensors | Accelerometer, Light Sensor |
Weight / Dimensions
| Weight | 0.73 kg (1.6 lbs) |
| Dimensions | 226 x 145 x 21.5 mm (8.9 x 5.7 x 0.8 in) |
Certification
| Certifications | CE, FCC Class B |
Warranty
| Warranty | Up to 3 Years |
