Tech Specs
Primary Components
| Processor Family | Intel Core I Series 8th Generation Kaby Lake R |
| Processor Model | Core i7-8550U |
| Processor Speed | 1.8 GHz |
| Memory Type | Onboard DDR4L |
| Memory Support | 16GB, 32GB (MOQ) |
| Storage Type | M.2 |
| Storage Support | 128GB (Standard), up to 1TB (Optional) |
Display
| Screen Size | 10.1" |
| Resolution | 1920 x 1200 (WUXGA) |
| Brightness | 400 nits |
Touch Screen
| Touch Screen | Projected Capacitive (Multi-touch) |
| Hardness | 7H |
| Glass Type | Gorilla Glass |
External I/O Ports
| USB | 1x USB 3.0, 1x USB Type C (USB 3.0, HDMI, Charging) |
| Video Outputs | 1x Mini HDMI |
| Other Ports | 1x TF Card Slot |
| Audio Ports | 1x 3.5mm Headphone Jack |
| Power Input Port | 4.0mm DC-in Jack |
Power
| Input Voltage Range | 19V DC |
Battery
| Battery Type | Internal 7.4V/860mAh Battery |
| Battery Operating Time | 8hrs (Default 50% volume, 50% Brightness, Playing 1080P Video) |
Operating Systems
| Windows | Windows 10 Pro, Windows 7 Pro |
Compatibility
| Security Hardware | TPM 2.0 |
Expansion Slots
| Expansion Module support | Choose 1 Option Only - Option 1: 1x Ethernet RJ45; Option 2: 1x D89(RS232) Serial port; Option 3: 1x USB 2.0; Option 4: 1x 1D Scanner- MOTO SE655E100R; Option 5: 1x 2D Scanner-Honeywell N3680" |
Multimedia
| Speakers | 1x 0.8W Speaker |
| Camera | Front: 2MP, Rear: 8MP w/ flash |
| Microphone | Built-in Microphone |
Thermal & Environmental
| Operating Temperature | -20°C - 60°C (-4°F – 140°F) |
| Storage Temperature | -30°C - 70°C (-22°F – 158°F) |
| Cooling Solution | Active – with Fan |
| Humidity Range | 5% – 95% Non-condensing |
| Storage Humidity | 5% – 95% Non-condensing |
Enclosure
| IP Rating | IP65 |
| Color | Black |
| Led Indicator Light | Battery, Power |
| Control Buttons | Audio Down, Audio Up, Home, Power Button, Scanner |
| Shock Rating | MIL-STD-810G Shock and Drop Resistant |
Peripherals & Wireless Connectivity
| WiFi | WIFI 802.11(a/b/g/n/ac) |
| Bluetooth | Bluetooth 4.2 |
| GPS | Ublox M8 |
| Mobile Network 4G LTE | Quectel EC25 M.2 Modules |
| Sim Card | 1x Micro SIM Card Slot |
| Barcode Scanner | Optional 1D/2D Barcode Scanner |
| Peripheral Other | Optional Fingerprint Reader, Optional NFC Reader |
| Sensors | Accelerometer |
Weight / Dimensions
| Weight | 1.22 kg (2.7 lbs) |
| Dimensions | 290 x 196 x 22 mm (11.4 x 7.7 x 0.9 in) |
Certification
| Certifications | IP65, MIL-STD-810G |
Warranty
| Warranty | 1 Year |
