Tech Specs
Primary Components
| Processor Family | Intel Celeron Bay Trail |
| Processor Model | N2930 |
| Processor Speed | 1.83 GHz |
| Memory Type | Onboard DDR3 |
| Memory Support | 4GB |
| Storage Type | 1x 2.5" SATA Drive Bay for SSD/HDD |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 18.5" |
| Resolution | Optional 1920 x 1080, 1366 x 768 |
| Screen Ratio | 16:9 |
| Brightness | Optional 1000 nit High Brightness, 300 nits |
Touch Screen
| Touch Screen | Projected Capacitive, Resistive |
External I/O Ports
| USB | 2x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232/422/485 DB-9, default RS-232(COM1), 1x RS-232 DB-9(COM2) |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 1x HDMI |
| Other Ports | 1x 2-Pin DC Power Switch Connector |
| Audio Ports | 1x Audio Line-Out |
| Power Input Port | Optional POE++, 45W with 2x USB 2.0, 3-Pin DC-In (Phoenix Type) |
Power
| Input Voltage Range | 9-36V DC |
| Standard Power Adapter | Optional 12V AC/DC Adapter |
Battery
| Battery Type | Optional Internal Battery |
Operating Systems
| Windows | Windows 10 IoT, Windows 10 Pro, Windows 8.1 Pro |
| Linux | Linux (Contact your sales rep for more information) |
Thermal & Environmental
| Operating Temperature | 0°C - 50°C (32°F – 122°F) |
| Storage Temperature | -20°C - 60°C (-4°F – 140°F) |
| Cooling Solution | Passive – Fanless with Heatsink |
| Humidity Range | 10% – 90% Non-condensing |
Enclosure
| Material | Aluminum |
| IP Rating | IP66 Front Bezel |
| Mounting Options | Panel Mount, VESA 100 Mount |
Peripherals & Wireless Connectivity
| WiFi | Optional WiFi |
| Bluetooth | Optional Bluetooth 4.0 |
| Mobile Network 4G LTE | Optional 4G |
Weight / Dimensions
| Weight | 5.9 kg (13.0 lbs) |
| Dimensions | 500 x 60 x 315 mm (19.7 x 2.4 x 12.4 in) |
Certification
| Certifications | CE, FCC Class A, UL 60950 |
Warranty
| Warranty | Up to 5 Years |
