Technische Daten
Primäre Komponenten
| Processor Family | Intel Celeron Bay Trail |
| Processor Model | N2930 |
| Processor Speed | 1,83 GHz |
| Memory Type | Onboard DDR3 |
| Memory Support | 4GB |
| Storage Type | 1x 2,5" SATA-Laufwerksschacht für SSD/HDD (leicht zugänglich) |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 15" |
| Screen Ratio | 4:3 |
| Brightness | 420 Nits, Optional 1000 nit hohe Helligkeit |
Touchscreen
| Touch Screen | Projiziert kapazitiv, Widerstandsfähig |
Externe E/A-Ports
| USB | 2x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232/422/485 DB-9, Standard RS-232(COM1), 1x RS-232 DB-9(COM2) |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 1x Optional HDMI |
| Audio Ports | 1x Audio-Line-Ausgang |
| Power Input Port | 3-poliger DC-Eingang (Phoenix-Typ) |
Leistung
| Input Voltage Range | 9-36V DC |
| Max Power Consumption | 20W |
| Standard Power Adapter | Optionaler 12V AC/DC Adapter |
Betriebssysteme
| Windows | Windows 10 IoT, Windows 10 Pro, Windows 7 Pro, Windows 8.1 Pro |
Thermisch & Umwelt
| Operating Temperature | 0°C - 50°C (32°F - 122°F) |
| Storage Temperature | -30°C - 70°C (-22°F - 158°F) |
| Cooling Solution | Passiv - Lüfterlos |
| Storage Humidity | 10% – 90% Non-condensing |
Gehäuse
| Material | Aluminium, Optional SUS316 Edelstahl, SUS304 Edelstahl |
| IP Rating | IP66 Frontblende, IP69K Frontblende |
| Mounting Options | Schalttafelmontage, VESA 100 Halterung |
Gewicht / Abmessungen
| Weight | 4.4 kg (9.7 lbs) |
| Dimensions | 422 x 322 x 54 mm (16.6 x 12.7 x 2.1 in) |
Zertifizierung
| Certifications | CE, EN 1672-2 Beanstandung (nur PCAP Touchscreen), FCC Klasse A |
Garantie
| Warranty | Bis zu 5 Jahre |
