Technische Daten
Primary Components
| Processor Family | Intel Celeron Bay Trail |
| Processor Model | N2930 |
| Processor Speed | 1,83 GHz |
| Memory Type | Onboard DDR3 |
| Memory Support | 4GB |
| Storage Type | 1x 2,5" SATA Laufwerksschacht für SSD/HDD |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 17" |
| Resolution | 1280 x 1024 (SXGA) |
| Screen Ratio | 4:3 |
| Brightness | Optional 1000 nit hohe Helligkeit, 350 Nits |
Touch Screen
| Touch Screen | Projiziert kapazitiv, Widerstandsfähig |
External I/O Ports
| USB | 2x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232/422/485 DB-9, Standard RS-232(COM1), 1x RS-232 DB-9(COM2) |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 1x HDMI |
| Other Ports | 1x 2-Pin DC Power Switch Anschluss |
| Audio Ports | 1x Audio-Line-Ausgang |
| Power Input Port | Optional POE++, 45W mit 2x USB 2.0, 3-poliger DC-Eingang (Phoenix-Typ) |
Power
| Input Voltage Range | 9-36V DC |
| Max Power Consumption | 48W |
| Standard Power Adapter | Optionaler 12V AC/DC Adapter |
Battery
| Battery Type | Optionale interne Batterie |
Operating Systems
| Windows | Windows 10 IoT, Windows 10 Pro, Windows 8.1 Pro |
| Linux | Linux (Wenden Sie sich für weitere Informationen an Ihren Vertriebsmitarbeiter) |
Thermal & Environmental
| Operating Temperature | 0°C - 50°C (32°F - 122°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Cooling Solution | Passiv – Lüfterlos mit Kühlkörper |
| Humidity Range | 10 % – 90 % nicht kondensierend |
Enclosure
| Material | Aluminium |
| IP Rating | IP66 Frontblende |
| Mounting Options | Schalttafelmontage, VESA-Halterung |
Peripherals & Wireless Connectivity
| WiFi | Optionales WiFi |
| Bluetooth | Optionales Bluetooth 4.0 |
| Mobile Network 4G LTE | Optional 4G |
Weight / Dimensions
| Weight | 5.1 kg (11.2 lbs) |
| Dimensions | 439 x 348 x 64.8 mm (17.3 x 13.7 x 2.6 in) |
Certification
| Certifications | CE, FCC Klasse A, UL 60950 |
Warranty
| Warranty | Bis zu 5 Jahre |
