Technische Daten
Primary Components
| Processor Family | Intel Core I series 7th Generation Kaby Lake |
| Processor Model | Core i5-7200U |
| Processor Speed | 2,5 GHz |
| Memory Type | 1x DDR4 SO-DIMM |
| Memory Support | 4GB, 8GB, 16GB |
| Storage Type | M.2, 1x 2,5" SATA Laufwerksschacht für SSD/HDD |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 23.8" |
| Resolution | 1920 x 1080 (Full HD) |
| Screen Ratio | 16:9 |
| Brightness | 250 nits |
Touch Screen
| Touch Screen | Projiziert kapazitiv (Multi-Touch) |
| Hardness | 7H |
External I/O Ports
| USB | 2x Optional USB 3.0, 4x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232, 1x RS-232/422/485 |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 2x DisplayPort |
| Audio Ports | 1x Audio-Line-Ausgang |
Power
| Standard Power Adapter | 100~240V / 47~63 Hz |
Battery
| Battery Type | Optionaler Hot-Swap-Akku |
Operating Systems
| Windows | Windows 10 IoT |
Compatibility
| Security Hardware | Optionales TPM 2.0, Optionales VPro |
Expansion Slots
| Video Card Support | Intel HD620 |
Multimedia
| Camera | Optionale 5MP-Webcam |
| Microphone | Eingebautes Mikrofon |
Thermal & Environmental
| Operating Temperature | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Cooling Solution | Passiv - Lüfterlos |
| Humidity Range | 10 % – 90 % nicht kondensierend |
| Storage Humidity | 10% – 90% Non-condensing |
Enclosure
| Material | Plastik |
| IP Rating | IP65 Frontblende |
| Color | Weiß |
| Led Indicator Light | Batterie, Fn-Taste, LCD ein/aus, Reinigen Sie mich |
| Control Buttons | Audio nach unten, Audio Up, Display ein/aus, Helligkeit oben, Helligkeit runter, Leselicht, Touchscreen-Sperre für die Reinigung |
| Programmable Function Buttons | 1x Programmierbare Funktionstaste |
| Mounting Options | Tisch montieren, VESA 100 Halterung |
| Approved Cleaning Solutions | Alkohol, Chlor und Verbindungen, Glutaraldehyd, Ortho-Phthalaldehyd (OPA), Quaternäre Ammonium-Verbindungen, Wasserstoffsuperoxyd |
Weight / Dimensions
| Weight | 9 kg (19.8 lbs) |
| Dimensions | 594 x 397 x 56 mm (23.4 x 15.6 x 2.2 in) |
Certification
| Certifications | CE, FCC Klasse B, IEC 62133, UL 60950, 60601-1 4. Auflage |
Warranty
| Warranty | 1 Jahr |
