Technische Daten
Primary Components
| Processor Family | Intel Core I series 6th Generation Skylake |
| Processor Model | Core i5-6200U |
| Processor Speed | 2,3 GHz |
| Memory Type | 2x DDR4 SO-DIMM |
| Memory Support | 4GB, 8GB, 16GB, 32 GB |
| Storage Type | M.2, mSATA, 1x 2,5" SATA Laufwerksschacht für SSD/HDD |
| Storage Support | 32GB-1TB |
Display
| Screen Size | 17" |
| Resolution | 1280 x 1024 (SXGA) |
| Screen Ratio | 5:4 |
| Brightness | 350 Nits |
Touch Screen
| Touch Screen | Projiziert kapazitiv, Widerstandsfähig |
| Hardness | Widerstandsfähig: 4H, P-cap: 7H |
External I/O Ports
| USB | 4x USB 3.0 |
| Serial / Com | 2x COM |
| Serial Protocol Detail | 1x RS-232, 1x RS-232/422/485 (RS485 unterstützt automatische Flusskontrolle) |
| Ethernet / LAN | 2x RJ45 GbE LAN |
| Video Outputs | 2x DisplayPort |
| Audio Ports | 1x 3.5mm Microphone Jack, 1x Audio-Line-Ausgang |
| Power Input Port | 4-polig DIN (rastend) |
Power
| Input Voltage Range | 9-32V Gleichstrom |
| Max Power Consumption | 61.4W |
| Standard Power Adapter | Optional, 100 Watt, Universal 100 ~240V AC Eingang, 12V DC Ausgang, 8,33A |
Operating Systems
| Windows | Windows 10 IoT, Windows 10 Pro, Windows 7 Pro |
Compatibility
| Security Hardware | Optionales TPM 2.0 |
Expansion Slots
| Internal M.2 | 1x M.2 Typ E |
| Video Card Support | Integrierte Intel HD-Grafik 520 |
Thermal & Environmental
| Operating Temperature | 0°C - 50°C (32°F - 122°F) |
| Storage Temperature | -20°C - 60°C (-4°F - 140°F) |
| Cooling Solution | Passiv - Lüfterlos |
| Humidity Range | 10 % – 90 % nicht kondensierend |
| Storage Humidity | 10% – 90% Non-condensing |
Enclosure
| Material | Aluminium, Optionale Lünette aus Edelstahl, Stahl |
| IP Rating | IP66 Frontblende |
| Color | Black |
| Control Buttons | Ein-/Aus-Taste, Power Reset |
| Mounting Options | Schalttafelmontage, VESA-Halterung |
Peripherals & Wireless Connectivity
| WiFi | Optional 802.11 ac + Bluetooth 4.0 mit externen Antennen |
Weight / Dimensions
| Weight | 8.5 kg (18.7 lbs) |
| Dimensions | 426.2 x 358.6 x 90 mm (16.8 x 14.1 x 3.5 in) |
Certification
| Certifications | CE, FCC Klasse B, VCCI |
Warranty
| Warranty | Up to 5 Years |
