● Fully enclosed NEMA 4X (IP65) stainless steel computer
● 19″ LCD display with SXGA resolution (1280×1024)
● 5-Wire resistive touch screen with tempered glass
● Intel Atom N270 1.6 GHz CPU, 2GB RAM /160GB HDD
● Food-safe rubber gaskets along the touch screen
● IP67 protected I/O Connectors with cables
● Different mounting options available
● Rugged, slim and very compact housing
TS-1210 Series Accessories:
Waterproof Cabel Set:
Wall Mount Bracket (stainless steel:
Table Stand (stainless steel):
Computing
Touch panel
| Processor / Socket | Intel Atom N270 1.6 GHz / On-board | |
| Chipset / FSB | Intel 945GSE & Intel ICH7M |
|
| Memory | 2 GB DDRII RAM |
|
| Mass storage | SATA 160 GB HDD |
|
| Expansion Bus |
1 x Mini PCIe extension |
|
| I/O interface | USB x 2 (4xUSB optional), RS232 x 2, RS232/422/485, LAN (Gigabit), DC-in | |
| Power requirement |
9-28V DC input: optional with
IP67 rating |
|
| Power consumption (Max.) | 2.8A at 12 V DC |
Mechanical & system
| Enclosure format | Chassis |
|
| Enclosure material | Stainless Steel |
|
| Enclosure protection | NEMA 4X (IP65) |
|
| Operating Temp. |
0-45C (32 -113F) |
|
| Mounting / Stand | . VESA 100x100 mm, Wall Mount,
Table Stand |
|
| Dimension (W x H x D) | 458 x 380 x 75 mm |
|
| Weight (Net) | 11.5 kg (approximate, w/ resistive touch) | |
| Certifications | FCC, CE, Class A |
|
| Extra features | |
. HDD anti-vibration . Watchdog timer . Temperature monitoring |
LCD panel
| Size & resolution | . Size: 19” LCD TFT Display
1280 x 1024 |
|
| Brightness | . Brightness: 350 nits |
|
| Light Transparency |
. 80 +/-3% |
Touch panel
Resistive |
. 5-wire Analog Resistive |
TS-1210-15 Stainless Steel PC
- 15” Touch computer
- Intel Atom 1.6GHz CPU
- Stainless steel Housing
- Fully NEMA 4X protected
