Industrial Touch PC 15"

S15-N10 Basic Touch PC

The S15 Basic is a universally usable industrial PC system especially for wet and dirty environments. The smooth and easy to clean stainless steel housing offers the perfect integration in to a wash-down environment. Depending on the requirements, the water proof stainless steel PC can be delivered with different all-in-one motherboards. The integrated on-board interfaces, such as Ethernet, USB, printer and serial interfaces allow the touch PCs to be used as standard desktop computer and also offer an easy integration into your IT environment. An easy connection with many custom peripherals is possible due to two standard PCI slots. In addition, the industrial touch PC offers optional a wireless LAN connectivity that enables the exchange of information and communication between server and client. This makes the waterproof computer perfect for food manufacturing or bottling applications.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

– Fully enclosed industrial 15″ Stainless Steel touch PC
- Processor: Up to Intel Core 2 Duo
- Display: 15″ TFT XGA (1024×768) – 430cd/m² with resistive Touch Screen
- Memory: 2GB up to 8 GB, Hard Disk: 160GB
- Network: Intel (82551) 10/100 MBit up to Intel (82551) 10/100/1000 MBit, WLAN
- Interfaces: 2x RS232, 5xUSB, Ethernet Network (RJ45), Monitor DVI-I, PS/2; 2xFirewire 40
- Expansions / Slots:Compact FLASH slot, Mini PCI, 2xPCI
- Operating Systems: Windows 7 Pro, XP Pro, XP Embedded, LINUX, QNX
- Environment: NEMA 4X, Temperature range 32° F up to 113° F (optional -4F-120F)

S15 Basic drawing of outer dimensions plus mounting bracket whole pattern:

Computing

Processor / Socket		Intel Celeron M 1.20GHz or Intel Core 2 Duo 2.2GHz
Chipset / FSB		Intel® Core™ 2 Duo SL9400 (2 x 1.86 GHz, 6 MB L2 Cache, 1066 MHz FSB)
Graphics		Intel® GMA 4500MHD (DirectX 10 3D Graphics Core)
Memory		8 GB maximum, 2 SO-DIMM-socket
Mass storage		160 GB HDD, SATA
Expansion		2x PCI or 2x PCI Express and 1x Mini-PCI
Audio		None
I/O interface		USB x 4, RS232, RS232/422/485, LAN (Gigabit), DVI-A/I, DC-in
Power supply		External, universal, 80 watts, DC-out: 24V (also NEMA 4X power supply available)
Power consumption (Max.)		W/ power supply: 60 watts

Mechanical & System

Enclosure format		All-In-One Washdown
Enclosure material		V2A Stainless Steel (1.4301) polished
Enclosure protection		. Front bezel: IP65 (NEMA4x) . Rear cover: IP65 (NEMA 4X)
Thermal management		45C operation - . Fanless: Yes . Smart fan : No . Enclosure heat-sink: None
Front bezel user control		Non
Mounting / Stand		. Wallmont: Yes . VESA 100x100 mm . Stand: Yes
Temperature		. Operating: 0° ~ 45° C . Storage: -20° ~ 65° C
Dimension (W x H x D)		16.6" x 12.3" x 3.9" (Wx H x D)
Weight (Net)		18.7 lbs
Certifications		FCC-A, CE(EMC/LVD), VCCI, UL/cUL
Extra features		. Automatic brightness control . Temperature monitoring & underclocking

LCD panel

Size & resolution		. Size: 15”, 4:3 . Resolution: 1024x768
Optical characteristic-1		. Brightness: 350 . Contrast: 700:1
Optical characteristic-2		. Viewing angle: 140/120 (H/V) . Response time: 8 ms (On+Off)
Backlight module		. Lamp: CCFL x 2 . Life: 70,000 hours
