TMP-177 Medical PC | Medical Computer

TMP-177 High Performance Medical PC

This streamline medical pc has been well-known for its superior IP65 HMI Human Machine Interface touch screen design. The white housing is made with an anti-bacterial coating. The fanless medical computer is built for many medical applications like, operating room, patient room, doctors and dentist clinics and many more. It is build with a powerful Core Duo Processor for a reliable and noiseless operation. The smooth design offers an easy wash down cleaning procedure. This medical pc helps to keep your environment clean. This is the perfect medical touch pc for a clean and quite application.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

Watch a Presentation about this Medical PC:

● High performance medical panel PC with medical Safety (UL 60601-1) compliance

● Anti-bacteria coating for the main unit plastic housing and stand

● Intel Core 2 Quad Q9100 2.26GHz processor

● Main-board design with Intel GME965 + ICH8M chip-set, 800 MHz FSB & socket BGA479

● 17” 5:4 1280×1024 SXGA LCD display with 380 nits brightness

● Plastic housing with IP65 rating front enclosure design

● Standard PCI & CF card slot

● Resistive touch panel optional integration

● Optional accessories of I/O cover kit, desktop stand, desktop & wall-mount arms

● Add-on application options of wireless LAN kit,

● Digital TV tuner kit camera module kit, and smart card reader kit

PMS 172 medical panel pc features

___________________________________________________________________________________

TMP-177 I/Os:

PMS 172 medical panel pc

___________________________________________________________________________________

Computing

Processor / Socket		Intel Core 2 Duo T7500 2.10 GHz, Celeron M 550 2.0 GHz / Socket BGA479
Chipset / FSB		Intel GME965 & Intel ICH8M / 800 MHz FSB
Graphics		Integrated Intel Graphics Media Accelerator X3100
Memory		4 GB maximum, dual channel, DDR2-667 SODIMM, slot x 2
Mass storage		SATA HDD, IDE CF card slot (standard)
Expansion		PCI, mini-PCI
Audio		. Amplifier: 2 W x 2 . Integrated speaker: 2 W x 2 (front bottom)
I/O interface		USB x 4, PS/2 x 2, RS232 x 2, RS232/422/485, VGA, DVI-D, LAN (Gigabit) x 2, line-in, line-out, microphone.-in, DC-in
Power supply		External, universal, 100 watts, DC-out: 12 V
Power consumption (Max.)		. W/ power supply: 101 watts . W/O power supply: 86 watts

Mechanical & system

Enclosure format		Chassis
Enclosure material		. Front: Plastic . Rear: Plastic
Enclosure protection		. Front bezel: IP65 . Rear cover: IPX1
Thermal management		. Fanless: No . Smart fan : Yes . Enclosure heat-sink: None
Front bezel user control		Membrane type, power on/off, brightness, volume
Mounting / Stand		. VESA 75x75 & 100x100 mm . Stand: Desktop, anti-bacteria
Temperature		. Operating: 0° ~ 40° C . Storage: -20° ~ 80° C
Dimension (W x H x D)		420 x 360 x 80 mm (approximate, w/o stand)
Weight (Net)		7.0 kg (approximate, w/o stand)
Certifications		FCC-B, CE, VCCI, UL/cUL, UL60601-1/EN60601-1 compliant
Extra features		. HDD anti-vibration . Temperature monitoring & underclocking . Watchdog timer . Kensington hole

LCD panel

Size & resolution		. Size: 17.0”, 5:4 . Resolution: 1280x1024
Optical characteristic-1		. Brightness: 380 . Contrast: 1000:1 . Color: RGB 6-bit + Hi-FRC data
Optical characteristic-2		. Viewing angle: 170/160 (H/V) . Response time: 5 ms (GTG)
Backlight module		. Lamp: CCFL x 4 . Life: 50,000 hours
