Fanless Medical PC | Medical Computer

T-192 – Fanless Medical PC

The T-192 medical computer has a flush HMI Human Machine Interface touch screen and an anti-bacterial coating. This seamless medical PC is built for many medical applications like operating room, patient room, doctors and dentist clinics and many more. It comes with a Core 2 Duo true fan less CPU for a reliable and noiseless operation. The fanless design of this powerful and 100% noiseless medical computer offers a smooth operation especial in hospitals and doctor's offices. The medical computer is designed for an easy wash-down procedure with its smooth and seamless housing that is IP54-rated at the front and IPX1-rated overall. The perfect medical computer with UL 60601 complies to keep your environment clean.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

Watch the product presentation:

● Fanless medical panel PC with medical Safety (UL 60601-1) compliance

● 19″ True Color high resolution diagnostic Display 1280×1024 SXGA, 350nits

● Flush and seamless front panel

● Plastic housing IP54-rated at the front and IPX1-rated overall

● Anti-bacteria coating for the main unit plastic housing and stand

● Intel ultra low voltage Core 2 Duo U7500 1.06 GHz processor, 10W TDP (thermal design power)

● Main-board design with Intel GME965 + ICH8M chip-set, 800 MHz FSB & socket BGA479

● Resistive touch panel PC optional integration

● Optional accessories of I/O cover kit, desktop stand, desktop & wall-mount arms

● Add-on application options of wireless LAN kit, digital TV tuner kit

● Camera module kit, and smart card reader kit

19" Medical Computer Interfaces:

Medical PC T191 Drawing:

Computing

Processor / Socket		Intel Core 2 Duo U7500 1.06 GHz / Socket BGA479
Chipset / FSB		Intel GME965 & Intel ICH8M / 800 MHz FSB
Graphics		Integrated Intel Graphics Media Accelerator X3100
Memory		4 GB maximum, dual channel, DDR2-667 SODIMM, slot x 2
Mass storage		SATA HDD, IDE CF card slot (standard)
Expansion		PCI, mini-PCI
Audio		. Amplifier: 2W x 2 . Integrated speaker: 2W x 2 (front bottom)
I/O interface		USB x 4, PS/2 x 2, RS232 x 2, RS232/422/485, VGA, DVI-D, LAN (Gigabit) x 2, line-in, line-out, microphone.-in, DC-in
Power supply		External, universal, 100 watts, DC-out: 12 V
Power consumption (Max.)		. W/ power supply: 65 watts . W/O power supply: 57 watts

Mechanical & system

Enclosure format		Chassis
Enclosure material		. Front: Plastic . Rear: Plastic
Enclosure protection		. Front bezel: IP65 . Rear cover: IPX1
Thermal management		. Fanless: Yes . Smart fan : No . Enclosure heat-sink: Yes
Front bezel user control		Membrane type, power on/off, brightness, volume
Mounting / Stand		. VESA 75x75 & 100x100 mm . Stand: Desktop, anti-bacteria
Temperature		. Operating: 0° ~ 40° C . Storage: -20° ~ 80° C
Dimension (W x H x D)		440 x 370 x 83 mm (approximate, w/o stand)
Weight (Net)		7.0 kg (approximate, w/o stand)
Certifications		FCC-B, CE, VCCI, UL/cUL, UL60601-1/EN60601-1 compliant
Extra features		. HDD anti-vibration . Watchdog timer . Temperature monitoring & underclocking . Kensington lock hole

LCD panel

Size & resolution		. Size: 19 ”, Wide . Resolution: 1280x1024
Optical characteristic-1		. Brightness: 350 . Contrast: 1000:1 . Color: RGB 64-bit + Hi-FRC data
Optical characteristic-2		. Viewing angle: 170/160 (H/V) . Response time: 5 ms (GTG)
Backlight module		. Lamp: CCFL x 4 . Life: 50,000 hours
