Panel PC | TP-1510-15

TP-1510-15

This Intel Atom Core Duo Panel mount PC has an ultra slim and fan less design suitable for a wide variety of industrial and commercial applications. The industrial panel pc is built with resilient and high-end components to ensure highest dependability in the worst environments. The streamlined T-7822-15A panel PC touch screen offers optional wireless LAN connectivity. A wide range of mounting options like panel mount or VESA mount can easily be deployed in a diverse range of applications. The fanless panel PC enables you to fully maximize your business output by making your process more efficient.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

● Fan-less Intel Atom Core Duo panel PC

● Slim housing with IP66/NEMA 4X front panel rating

● Intel Atom D525 1.8 GHz processor, up to 4GB RAM, 160GB HDD

● Main-board design with Intel® ICH8M chip set + 800MHz FSB

● 15” 4:3 800×600 SVGA LCD display with 230 nits brightness

● 5-wire resistive or capacitive touch panel integration

● Add-on options of CF & wireless LAN kit

CPU		Atom D525 1.8GHz
Chipset / FSB		Intel® ICH8M chipset + 800MHz FSB
Graphic		Analog CRT up to 2048x1536, support for CRT hot plug 18/24-bit single/dual-channel LVDS by Xilinx XC3S200AN, resolution support up to 800x600, 1024x768, 1280x1024, 1920x1080
Audio		Realtek ALC286 Audio Codec, 2+2 watts power amplifier
LAN		Marvell 88E8071 Gigabit Ethernet x 1
Memory		Single Channel two DDR3 SODIMM socket supports up to 4GB
I/O		ICH8M
Serial ATA		SATA II controller (3.0Gb/sec) Port x 2
USB		External USB 2.0 type A x 3
		Internal Mini-PCIE x 1 (for Wifi) 3.3V socket x 2 (for Webcam & Blue tooth) 5V Pin Head to expansion x 2
WDT		Generates system reset; 256 segments, 0, 1, 2…255 sec.

LCD Panel

Size		15''
Resolution (pixel)		1024x768 XGA
Number of Colors		16.7M
Color Saturation (NTSC %)		50
View Angle (H/V)		140/140
Brightness (cd/m2)		300
Contrast Ratio		800:1
Response Time (ms) (at 25°C)		35
Power Consumption (W)		10.77W
Interface		8bit LVDS
Supply Voltage (V)		3.3
Backlight		CCFL
Outline Dimensions (mm)		279x209x11
life time		50000
Operating temp.		0-50℃

Touch Screen

	3M	AMT
Model name	17-8581-203	AD-28116
Type	CAP	5 wire RES
Glove	Only very thin latex glove	Any type glove
Stylus	Need special conductive stylus	No Limitation, can use any stylus
Interface	COM Port	USB
Light Transmission	91.5%	80±3%
Hardness	Mohs 7	3H
Glass thickness	3.18mm	1.8mm
Linearity	99.0%	X≦1.5%, Y≦1.5%
Active area	205.74x158.75	212x159.20
Resolution	4096X4096	4096x4096
Lifetime	200 million touches	36 million activations

Mechanical & Environmental

Material construction	Front bezel is Aluminum or SECC, others are SECC enclosure
Aluminum bezel Color	Black / Silver
Front Panel Protection	IP66/NEMA4X
ID design	Panel mount, Open frame
Operation Temperature	0~50℃ (IEC60068-2-56, air flow cooling)
Storage Temperature	-20~65℃
Operation Relative Humidity	10%~90%, non-condensing
Storage Relative Humidity	10%~90%, non-condensing
Dimensions	Panel mount: 369x290x55 mm
Net Weight	6.6kg
Mounting	Panel mount/VESA (75x75)
Regulatory	FCC-A, CE (EMC), VCCI, UL/cUL
