Fanless Panel PC | TP-1510-10

TP-1510-10

This 10" Intel Atom Core Duo D525 fanless panel PC is designed to be suitable for a wide range of industrial and commercial applications that enable you to fully realize your business potential. The ultra slim and fanless panel pc TP-1510-10 utilizes a high performance Intel Atom 1.8GHz CPU board with very low power consumption. Optional wireless connectivity of this industrial computer enables the exchange of data utilizing onsite wireless networks. The fanless panel PC design, its low power consumption and many mounting options make this unit versatile and suitable for a wide range of applications.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

● Fan-less Intel Atom Core Duo panel PC

● Slim housing with IP66/NEMA 4X front panel rating

● Intel Atom Core Duo D525 1.8 GHz processor, up to 4GB RAM, 160GB HDD

● Main-board design with Intel® ICH8M chip set + 800MHz FSB

● 10.4” 4:3 800×600 SVGA LCD display with 230 nits brightness

● 5-wire resistive or capacitive touch panel integration

● Add-on options of CF & wireless LAN kit

CPU		Atom D525 1.8GHz
Chipset / FSB		Intel® ICH8M chipset + 800MHz FSB
Graphic		Analog CRT up to 2048x1536, support for CRT hot plug 18/24-bit single/dual-channel LVDS by Xilinx XC3S200AN, resolution support up to 800x600, 1024x768, 1280x1024, 1920x1080
Audio		Realtek ALC286 Audio Codec, 2+2 watts power amplifier
LAN		Marvell 88E8071 Gigabit Ethernet x 1
Memory		Single Channel two DDR3 SODIMM socket supports up to 4GB
I/O		ICH8M
Serial ATA		SATA II controller (3.0Gb/sec) Port x 2
USB		External USB 2.0 type A x 3
		Internal Mini-PCIE x 1 (for Wifi) 3.3V socket x 2 (for Webcam & Blue tooth) 5V Pin Head to expansion x 2
WDT		Generates system reset; 256 segments, 0, 1, 2…255 sec.

LCD Panel

Size		10.4''
Resolution (pixel)		SVGA (800 x 600)
Number of Colors		262K
Color Saturation (NTSC %)		50
View Angle (H/V)		130/110
Brightness (cd/m2)		230
Contrast Ratio		400:1
Response Time (ms) (at 25°C)		25
Power Consumption (W)		3.227W
Interface		LVDS
Supply Voltage (V)		3.3V
Backlight		CCFL
Outline Dimensions (mm)		236×176.9×5.6
Weight (g)		300
life time		20000
Operating temp.		-20-70℃

Touch Screen

	3M	AMT
Model name	SCT3250EX	AD-2527
Type	CAP	5 wire RES
Glove	only very thin latex glove	any type of glove
Stylus	requires special conductive stylus	no limitation
Vandal	NA	NA
Interface	COM Port	USB
Light Transmission	91.5%	80±3%
Hardness	Mohs 7	3H
Glass thickness	3.18mm	1.8mm
Linearity	99.0%	X≦1.5%, Y≦1.5%
Active area	205.74x158.75	212x159.20
Resolution	4096X4096	4096x4096
Lifetime	200 million touches	36 million activations

Mechanical & Environmental

Materialconstruction	Front bezel is Aluminum or SECC, others are SECC enclosure
Aluminum bezel Color	Black / Silver
Front Panel Protection	IP66/NEMA4X
ID design	Panel mount, Open frame
Operation Temperature	0~50℃ (IEC60068-2-56, air flow cooling)
Storage Temperature	-20~65℃
Operation Relative Humidity	10%~90%, non-condensing
Storage Relative Humidity	0%~90%, non-condensing
Dimensions	Panel mount: 313×240×49 mm
Net Weight	3.8 Kg
Mounting	Panel mount/VESA (75x75)
Regulatory	FCC-A, CE (EMC), VCCI, UL/cUL
