Fanless Panel PC 15"

T-7822-15A-OF – 15″ Open Frame Panel PC

The Intel Atom open frame fanless panel PC has an ultra slim and fan less design suitable for a wide variety of industrial and commercial applications. The industrial touch screen pc is built with strong and high-end components to ensure highest reliability in the worst environments. The streamlined T-7820-15A panel PC touch screen offers optional a wireless LAN connectivity. The wide range of mounting options like open frame panel mount or VESA mount can easily be implemented in a diverse range of application. The fanless panel PC enables you to fully maximize your business output by making your process efficient.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

● Fan-less Intel Atom Touch Open Frame Panel PC

● Ultra slim housing with for open frame application

● Intel Atom N270 1.6 GHz processor, up to 2GB RAM / 160GB HDD

● Main board design with Intel 945GSE + ICH7M chip-set, 533 MHz FSB

● 15” 4:3 12024 x 768 XGA LCD display with 350 nits brightness

● Rugged and solid aluminum enclosure

● 5-wire resistive or capacitive touch screen integration

● Add-on options of CF & DOM memory card, wireless LAN kit

panel pc touch screen

__________________________________________________________________________________

15" Intel Atom Open Frame Panel PC I/Os:

industrial touch pc

Computing

Processor / Socket		Intel Atom N270 1.6 GHz / On-board
Chipset / FSB		Intel 945GSE & Intel ICH7M / 533 MHz FSB
Graphics		Integrated Intel Graphics Media Accelerator 950
Memory		2 GB maximum, single channel, DDR2-533 SODIMM, slot x 1
Mass storage		SATA HDD, IDE CF, IDE DOM
Expansion		Mini-PCI-e
Audio		. Amplifier: 2W x 2 . Integrated speaker: None
I/O interface		USB x 4, PS/2 x 2, RS232 x 2, RS232/422/485, LAN (Gigabit) x 2, VGA, line-in, line-out, microphone.-in, DC-in
Power supply		External, universal, 80 watts, DC-out: 12 V
Power consumption (Max.)		. W/ power supply: 50 watts . W/O power supply: 50 watts

Mechanical & system

Enclosure format		Open frame
Enclosure material		. Front: Aluminum . Rear: SECC
Enclosure protection		. Front bezel: IP65 . Rear cover: IP1X
Thermal management		. Fanless: Yes . Smart fan : None . Enclosure heat-sink: Rear cover
Mounting / Stand		. VESA 75x75 mm . Stand: None
Temperature		. Operating: 0° ~ 40° C . Storage: -20° ~ 80° C
Dimension (W x H x D)		398 x 330 x 70 mm (panel mount, approximate)
Weight (Net)		7.0 kg (panel mount, approximate)
Certifications		FCC-A, CE(EMC/LVD), VCCI, UL/cUL
Extra features		. HDD anti-vibration . Watchdog timer . Temperature monitoring & underclocking

LCD panel

Size & resolution		. Size: 15.0”, 4:3 . Resolution: 1024x768
Optical characteristic-1		. Brightness: 300 . Contrast: 800:1 . Color: RGB 6-bit + FRC data
Optical characteristic-2		. Viewing angle: 140/140 (H/V) . Response time: 8 ms (R+F)
Backlight module		. Lamp: CCFL x 2 . Life: 50,000 hours
