16:9 21.6″ Fanless Panel Computer
Full HD LCD Display 1920 x 1080
Intel® Atom™ N270, Low Consumption CPU
2nd Display VGA Port
Dual GbE
2 x USB/1 x Mini-PCI/1 x CF/1 x RS232/422/485
Optional Touch Screen, WiFi Module, 2.5” HDD
DDR2 1GB (Onboard 1GB up to 2GB)
2.5” HDD Bracket
Two Speakers
CF as Default (DVI/COM2/TV-Out as Optional)
+12V Power Adaptor
Dimension: 508mm (W) x 301mm (H) x 53.9mm (D)
| LCD Panel Specification |
| Viewable Size Image | 21.5"(16:9) |
| |
| Active Display Area | 476.64 (H) x 268.11 (V) |
| |
| Pixel Pitch | 248.25 (per one triad)(H) ×248.25(V) |
| |
| Pixels | 1920x1080 |
| |
| Contrast Ratio | 1000:1 (typ.) |
| |
| Display Color | 16.7M (8bits/color) |
| |
| Brightness | 300 (typ.) |
| |
| Viewing Angle | 170 (H); 160 (V) |
| |
| Recommend Resolution | 1920x1200 @60Hz |
| |
| Power source | AC110~240V,Universal, ±10% |
| |
| Power Consumption | 35 W typical, normal operation |
| |
| Power Management | VESA DPMS Compliant |
| |
| Plug Play | VESA DDC 1/2B |
| |
| Optional TouchScreen | Resistive |
| |
|
| System Specification |
| Form Factor | Mini-ITX |
| |
| Processor | Intel® Atom N270 1.6GHz Processor |
| |
| Front Side Bus | 533 MHz |
| |
| System Chipset | Intel® 945GSE / ICH7M |
| |
| System Memory | 1 x 240-pin DDR2 DIMM, max.2GB (Default 1GB DDR533 |
| |
| BIOS | AMI 4Mbit |
| |
| VGA Controller | Intel® 945GSE integrated |
| |
| VGA Memory | Shared memory, max.224MB |
| |
| LCD Support | Dual Channel 18-bit LVDS (Optional Dual Channel 24-bit LVDS) |
| |
| Ethernet | Dual Realtek RTL8111B Gigabit LAN Controller |
| |
| Audio | Built-in audio + AC97 codec |
| |
| IDE | 1 x 44pin IDE (UDMA33/66/100) |
| |
| SATA | 2 x SATAII |
| |
| I/O Chipset | Winbond W83627EHG |
| |
| Serial | 1 x RS-232/422/485* on backside I/O) |
| |
| USB | 2 x USB ( 2 x USB on backside I/O) |
| |
| KB / Mouse Connector | Non |
| |
| Watchdog Timer | 256 Levels |
| |
| SDD Interface | 1 x Type I/II CF Socket(Optional) |
| |
| DVD Optional | NO |
| |
| HDD | 2.5 inch 160GB |
| |
| FDD Optional | No |
| |
| OS Optional | Windows XP Embedded/
Windows XP Pro, Windows 7 Pro. |
| |
| Power Adapter | DC IN 12V |
| |
| Temperature | Operating : 0 deg.C to 45 deg.C |
| |
| Humiduty | 30% to 90% non condensing |
| |
| Shock | Operating:15G, 11ms duration |
| |
| Vibration | Operating: 5 Hz ~ 500 Hz/ 1 Grms/ 3 Axis
Packing:: 5 Hz ~ 500 Hz/ 2.16 Grms/ 3 Axis |
| |
