Industrial Panel PC 19"

T-7821-19M Industrial Panel PC

The T-7821-19M Touch Screen Panel is a high performance and high quality industrial panel PC. It is designed to provide versatile and cost-effective solutions to enable you to fully maximize your business output. The touch screen is built-in with a NEMA 4X (IP65) front bezel which is available in black or silver aluminum or in stainless steel. Only strong and high quality industrial components are used in this panel PC to ensure highest reliability in all kinds of industrial or commercial applications. The powerful and fanless T-7821-19M industrial touch PC is designed with an ultra slim housing for space-efficient implementation. To enable the exchange of information and communication between server and clients the touch panel PC is also available with a built-in wireless LAN card. Due to a wide range of mounting options like panel mount or VESA mount, the system can easily be implemented in a diverse range of applications.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

● Fanless panel mount PC

● Intel high performance Core Duo T2500 2.0 GHz processor

● Intel power saving Core Duo L2400 1.66 GHz processor, 15W TDP (thermal design power)

● Main-board design with Intel 945GME + ICH7M chip-set, 667 MHz FSB & socket M

● 19” 5:4 1280×1024 SXGA LCD display with 350 nits brightness

● Complete touch panel integration of resistive, capacitive, IR, SAW and projective capacitive

● Rugged enclosure with aluminum housing for best heat dissipation

● IP65 rating front enclosure design in black or silver aluminum

● Add-on options of wireless LAN kit and TV tuner card kit

industrial panel pc

Computing

Processor / Socket		Intel Core Duo T5200 2.0 GHz, L2400 1.66 GHz; Celeron M M540 1.86 GHz / Socket M
Chipset / FSB		Intel 945GME & Intel ICH7M / 667MHz FSB
Graphics		Integrated Intel Graphics Media Accelerator 950
Memory		2 GB maximum, dual-channel, DDR2-667 SODIMM, slot x 2
Mass storage		SATA HDD, IDE CF (internal)
Expansion		Mini-PCI
Audio		. Amplifier: 2W x 2 . Integrated speaker: None
I/O interface		USB x 4, PS/2, RS232 x 3, RS232/422/485, DVI-D, LAN (Gigabit), line-in, line-out, microphone.-in
Power supply		External, universal, 80 watts, DC-out: 12 V
Power consumption (Max.)		. W/ power supply: 88 watts . W/O power supply: 75 watts

Mechanical & system

Enclosure format		Panel mount, Open frame, Chassis
Enclosure material		. Front: Aluminum . Rear: Steel
Enclosure protection		. Front bezel: IP65 . Rear cover: IP1X
Thermal management		. Fanless: Yes . Smart fan: None . Enclosure heat-sink: None
Mounting / Stand		. VESA 75x75 & 100x100 mm . Stand: None
Temperature		. Operating: 0° ~ 40° C . Storage: -20° ~ 60° C
Dimension (W x H x D)		515 x 396 x 77~80 mm (varies with different touchs)
Weight (Net)		8 ~ 9.8 kg (varies with different touchs)
Certifications		FCC-A, CE(EMC/LVD), VCCI, UL/cUL
Extra features		. HDD anti-vibration . Watchdog timer . Temeprature monitoring & underclocking . Kensington lock hole

LCD panel

Size & resolution		. Size: 19.0”, 5:4 . Resolution: 1280x1024
Optical characteristic-1		. Brightness: 350 . Contrast: 1300:1 . Color: RGB 32-bit
Optical characteristic-2		. Viewing angle: 178/178 (H/V) . Response time: 8 ms (GTG)
Backlight module		. Lamp: CCFL x 4 . Life: 50,000 hours

Touch panel

Resistive		. Light transmission: > 80% . Hardness: 3H . 5-Wire, AG coating
Capacitive		. Light transmission: 91.5% . Hardness: 7 Mohs . AG coating
