T-7822-10A Fanless Panel PC

The 10" Intel Atom fanless panel PC has a space-saving design that fits into a wide range of industrial and commercial applications to enable you to fully maximize your business potential. The ultra slim and fanless panel pc T-7820-10A includes a high performance Intel Atom 1.6GHz CPU board with very low power consumption. The optional wireless connectivity of this industrial computer enables the exchange of information. The portable and light fanless panel PC design is suitable with many circumstances. A wide range of mounting options can easily be implemented in a diverse range of application. Mounting options are panel mount or VESA mount. It can also be used as an all-in-one PC.

Get Quote

• Features
• Tech Specs
• Detail View
• Product Images
• Related Products
• Get Data Sheet

● Fan-less Intel Atom panel PC

● Slim housing with IP65 rating front enclosure design

● Intel Atom N270 1.6 GHz processor, 2GB RAM, 160GB HDD

● Main-board design with Intel 945GSE + ICH7M chip-set, 533 MHz FSB

● 10” 4:3 800×600 SVGA LCD display with 300 nits brightness

● Rugged enclosure with aluminum front bezel and rear cover with external heat-sink

● 5-wire resistive touch panel integration

● Add-on options of CF & DOM memory card, wireless LAN kit

Fully integrated I/O :
___________________________________________________________________________________

Technical Drawings:
___________________________________________________________________________________

Computing

Processor / Socket		Intel /BGA /Atom N2701.6G Single Core/533MHZ/2.5W
Chipset / FSB		Intel® 945GSE chipset + ICH7M / 533 MHz FSB
Graphics		Intel Generation 3.5 integrated GFX Core (133 MHz) on board
Memory		2 GB maximum, single channel, DDR2-533/667 SODIMM, slot x 1
Mass storage		SATA/IDE HDD, IDE CF
Expansion		Mini-PCI
Audio		. Amplifier: 2W x 2 . Integrated speaker: None
I/O interface		USB x 4, PS/2, RS232 x 2, RS232/422/485, LAN (10/100 Base-T), line-in, line-out, microphone.-in, DC-in
Power supply		External, universal, 50 watts, DC-out: 12 V
Power consumption (Max.)		A. High brightness . W/ power supply: 41 watts . W/O power supply: 35 watts B. Normal brightness . W/ power supply: 31 watts . W/O power supply: 27 watts

Mechanical & system

Enclosure format		Panel mount, Open frame, Chassis
Enclosure material		. Front: Aluminum . Rear: SECC
Enclosure protection		. Front bezel: IP65 . Rear cover: IP1X
Thermal management		. Fanless: Yes . Smart fan : None . Enclosure heat-sink: Rear cover
Mounting / Stand		. VESA 75x75 mm . Stand: None
Temperature		. Operating: 0° ~ 40° C . Storage: -20° ~ 80° C
Dimension (W x H x D)		313 x 240 x 48~52 mm (approximate, varies with different touch)
Weight (Net)		3.5 kg (approximate, varies with different touch)
Certifications		FCC-A, CE(EMC/LVD), VCCI, UL/cUL
Extra features		. HDD anti-vibration

LCD panel - High brightness

Size & resolution		. Size: 10.4”, 4:3 . Resolution: 800x600
Optical characteristic-1		. Brightness: 400 . Contrast: 500:1 . Color: RGB 6-bit
Optical characteristic-2		. Viewing angle: 140/120 (H/V) . Response time: 35 ms (R+F)
Backlight module		. Lamp: CCFL x 2 . Life: 50,000 hours

LCD panel - Normal brightness

Size & resolution		. Size: 10.4”, 4:3 . Resolution: 800x600
Optical characteristic-1		. Brightness: 230 . Contrast: 500:1 . Color: RGB 6-bit
Optical characteristic-2		. Viewing angle: 140/120 (H/V) . Response time: 35 ms (R+F)
Backlight module		. Lamp: CCFL x 1 . Life: 30,000 hours

Touch panel

Resistive		. Light transmission: 80+-3% . Hardness: 3H . 8-Wire, AG coating
Capacitive		. Light transmission: 91.5+-1.5% . Hardness: 7 Mohs . AG coating
Infrared		. Light transmission: >=90% . Hardness: 7 Mohs . Toughened glass
