Touch Panel PC 17"

T-7821-17M-AIO All In One Touch Panel PC

This 17" LCD TFT All-In-One Panel PC is a high performance and high quality industrial computer. The space-saving enclosure with a NEMA 4X front bezel is designed for many industrial and commercial applications enabling you to streamline your processes efficiently. The industrial panel PC is built with strong and high-end components to ensure highest reliability in high demanding industrial applications. The powerful and truly fanless panel pc T-7821-17M-AIO has an ultra slim design. Another advantage is that the touch screen offers optional wireless N connectivity that enables the exchange of information and communication between administers and clients. The wide range of mounting options can easily be implemented in a diverse range of application.

Get Quote

Features
Tech Specs
Detail View
Product Images
Related Products
Get Data Sheet

● 17″ TFT LCD All In One Touch Panel PC

● Only 78 mm thick housing with IP65 /NEMA 4X rating front enclosure design

● Intel Core Duo 2.16 GHz CPU (fanless)

● Main-board design with Intel 945GME chipset + ICH7M

● 17” 5:4 1280×1024 SXGA LCD display with 300 nits brightness

● Rugged enclosure with aluminum front bezel and rear cover with external heat-sink

● 5-wire resistive or capacitive touch panel integration

● Add-on options of CF slot, wireless LAN kit, dual ports gigabyte LAN card

● Optional customized integrated 2W x 2 speakers with dedicated front bezel

Computing

Processor / Socket		Intel® Core™ Duo 2.16G (31W)
Chipset / FSB		Intel 945GME chipset + ICH7M
Graphics		Integrated Intel Graphics Media Accelerator 950
Memory		4 GB maximum, dual-channel, DDR2-667 SODIMM, slot x 2
Mass storage		SATA HDD, IDE CF (internal)
Expansion		Mini-PCI
Audio		Amplifier: 2W x 2 . Integrated speaker: None
I/O interface		ICH7M
Serial ATA		Port x 1 with 150 MB/s transfer rate x 1
WDT		1~255 seconds, software programmable

Mechanical & system

Enclosure format		Aluminum
Color		Black/Silver
ID design		1. Panel mount / Chassis housing for option 2. Open frame
Mounting / Stand		VESA 75x75 & 100x100 mm . Stand: None
Temperature		Operating: 0° ~ 40° C . Storage: -20° ~ 60° C
Dimension (W x H x D)		477.2x362x78 (panel mount) 438.2x339.5x73(openframe)
Weight (Net)		8.8 (panel mount)7.4 (openframe)
Certifications		FCC-A, CE(EMC/LVD), VCCI, UL/cUL
Extra features		HDD anti-vibration . Watchdog timer . Temperature monitoring & underclocking Kensington lock hole

LCD panel

Size & resolution		Size: 17.0”, 5:4 . Resolution: 1280x1024
Optical characteristic-1		Brightness: 380 . Contrast: 800:1 . Color: RGB 6-bit + FRC data
Optical characteristic-2		Viewing angle: 170/160 (H/V) . Response time: 5 ms (GTG)
Backlight module		Lamp: CCFL x 4 . Life: 50,000 hours

Touch panel

Resistive		Light transmission: > 80% . Hardness: 3H . 5-Wire, AG coating
Capacitive		Light transmission: 91.5% . Hardness: 7 Mohs . AG coating
