TP-1220-22 Full HD Panel PC
This great 21.5" Full HD panel pc has a slim fan-less design suitable for a wide variety of industrial and commercial applications. It is built with a full HD wide angle TFT LCD display which offers an extremely clear picture. This touch panel pc is built with strong high-end components to ensure the highest reliability in harsh environments. The streamlined T-1220-22 Panel PC offers a wireless LAN connectivity option. The wide range of mounting options like panel mount or VESA mount can easily be implemented in a diverse range of applications. The industrial PC enables you to fully maximize your business output by making your process more efficient.
Get Quote
21.5″ TFT LCD Display with full HD Resolution (1920×1080)
Resistive Touch Screen (5 Wire)
Intel® Atom N270 1.6GHz Processor
1 x SO-DIMM, max. 2GB DDR2 400/533
Integrated VGA, 224MB shared
Integrated Dual Realtek RTL8111B Gigabit LAN Controller
1 x PCI , 1 x Mini PCI, 4 x COM, 8 x USB 2.0
Slim Profile: Only 69 mm (2.72″) in depth
22" Panel PC Interfaces:
22" Fanless Panel PC Mechanical Design:
Technical Drawing:
| LCD
Panel Specification |
| Viewable Size Image |
21.5"(16:9) |
|
|
| Active Display Area |
476.64 (H) x 268.11 (V) |
|
|
| Pixel Pitch |
248.25 (per one triad)(H) ×248.25(V) |
|
|
| Pixels |
1920x1080 |
|
|
| Contrast Ratio |
1000:1 (typ.) |
|
|
| Display Color |
16.7M (8bits/color) |
|
|
| Brightness |
250 (typ.) |
|
|
| Viewing Angle |
-85~85 (H); -80~80 (V) |
|
|
| Recommend Resolution |
1920x1080 @60Hz |
|
|
| Power source |
AC110~240V,Universal, ±10% |
|
|
| Power Consumption |
35 W typical, normal operation |
|
|
| Power Management |
VESA DPMS Compliant |
|
|
| Plug Play |
VESA DDC 1/2B |
|
|
| Optional TouchScreen |
Resistive |
|
|
|
| System
Specification |
| Form Factor |
Mini-ITX |
|
|
| Processor |
Intel® Atom N270 1.6GHz Processor |
|
|
| Front Side Bus |
533 MHz |
|
|
| System Chipset |
Intel® 945GSE / ICH7M |
|
|
| System Memory |
1 x 240-pin DDR2 DIMM, max.2GB (Default
1GB DDR533 |
|
|
| BIOS |
AMI 4Mbit |
|
|
| VGA Controller |
Intel® 945GSE integrated |
|
|
| VGA Memory |
Shared memory, max.224MB |
|
|
| LCD Support |
Dual Channel 18-bit LVDS (Optional Dual
Channel 24-bit LVDS) |
|
|
| Ethernet |
Dual Realtek RTL8111B Gigabit LAN
Controller |
|
|
| Audio |
Built-in audio + AC97 codec |
|
|
| IDE |
1 x 44pin IDE (UDMA33/66/100) |
|
|
| SATA |
2 x SATAII |
|
|
| I/O Chipset |
Winbond W83627EHG |
|
|
| Serial |
3 x RS-232, 1 x RS-232/422/485*(2 x RS-232, 1 X RS-232/422/485*
on backside I/O) |
|
|
| USB |
8 x USB ( 4 x USB on backside I/O) |
|
|
| KB / Mouse Connector |
2 x PS/2 |
|
|
| Watchdog Timer |
256 Levels |
|
|
| SDD Interface |
1 x Type I/II CF Socket(Optional) |
|
|
| DVD Optional |
YES |
|
|
| HDD |
3.5 inch 80GB |
|
|
| FDD Optional |
No |
|
|
| OS Optional |
Windows XP Embedded/
Windows XP Professional Embedded |
|
|
| Power Adapter |
DC IN 12V |
|
|
| Temperature |
Operating : 0 deg.C to 45 deg.C |
|
|
| Humiduty |
30% to 90% non condensing |
|
|
| Shock |
Operating:15G, 11ms duration |
|
|
| Vibration |
Operating: 5 Hz ~ 500 Hz/ 1 Grms/ 3 Axis
Packing:: 5 Hz ~ 500 Hz/ 2.16 Grms/ 3 Axis |
|
|
