TB-1630 Embedded PC

The TB-1630 fully fanless Embedded PC is an incredibly ruggedized system designed to withstand extended temperatures up to 55°C and down to -25°C while exhibiting resistance to vibration and shock. The platform features two DVI outputs, 3 RS-232 COM (via RJ45 connectors and optional break-out cables), 4 USB 2.0 ports, and front access to CompactFlash. Dual Gb LAN makes this an ideal solution for a great variety of applications. It also comes with 1 GB DDR2 533 on-board wide temperature range memory. This great fanless Embedded PC has a small footprint and low profile, measuring 30mm height, making it easy to install in remote locations for set-it-and-forget-it computing. This system is ideal for industrial control, construction, manufacturing, and remote deployments. In addition, swap out the notebook HDD with a 2.5" SATA SSD for the reliability of a solid state platform.

Get Quote

• Features
• Tech Specs
• Detail View
• Product Images
• Related Products
• Get Data Sheet

● Intel Atom Dual Core N2600 1.6 GHz processor

● Fanless

● Ultra Low Profile Enclosure with Wall-Mount Brackets

● Up to 4GB RAM / 160GB HDD or SSD Option

● RS-485 Auto-flow Function Supported

● Support Outside Accessible SD Slot

● Support Optional WiFi Connection

● Rugged Design for Shock/Vibration Protection

TB-1630 Embedded PC Technical Drawing:

System Specification
Processor	Intel Atom N2600 1.6 GHz processor
Graphics	Integrated with Atom N2600
System Chipset / LAN Chipset	Intel® NM10 / 2 x Realtek 8111 Gigabit Ethernet controllers
System Memory	1 x 204 pin DDR3 SO-DIMM Socket supporting 800/1066 MHz SDRAM up to 2 GB
Storage	320 GB HDD or 32GB Industrial SSD or 1 x SD Socket (accessible from the outside)
Audio	Mic-in/ 2 x Line-out  (500mW pre-amplified)
Peripherals and Devices
WLAN	Optional, 1 x Mini-card slot for optional WiFi module
Serial Port	1 x DP-9 male connector, RS232/422/485 selectable
LAN	2 x RJ-45 port for Gigabit Ethernet
Video Port	1 x DVI-I female connector for Digital Video Output, 1 x DVI-D female connector for Digital Video Output
USB Port	4 x USB 2.0 ports
Mechanical and Environment
Dimensions (W x D x H)	190 x 150 x 30 mm (7.48" x 5.91" x 1.18")
Construction	Aluminum Alloy
Operating Temperature	-25 ~ 55C (-13F ~ 131F), ambient with air flow
Mounting	Supports VESA-mount/wall mounting
Relative Humidity	10 to 95% @ 40C (non-condensing)
Certifications	CE/FCC
Power Management
Power Input	DC 19V input
Power Consumption	20 W max.
